SENIOR LIVING



ABINGDON AT TRADITION

1/3

Continuing Care Retirement Community

Port St. Lucie, FL

TDG was retained by Senior Living Communities to provide Architectural, Structural, Mechanical, Electrical and Plumbing design services for the new campus at Port St. Lucie in Port St. Lucie, FL.  The campus includes a 20,000 SF Clubhouse, three 43,500 SF Apartment Buildings, a 13,395 SF Assisted Living Building with a 14,854 SF Alzheimer’s Care Building, a Wellness Center that includes an indoor therapy pool, a 1,000 SF maintenance building, and a gatehouse and gazebo. The Clubhouse is a two-story structure with dining rooms to seat 240 people, a kitchen, an activities room, a library and offices and other support spaces.  The Apartment Buildings are three-story structures with 30 units each.  The Assisted Living Building is a single story structure containing 23 residential beds.  The Alzheimer’s Care Building is a single-story structure with 32 beds. The campus also includes an outdoor pool and bathhouse for all residents.

SERVICES: Architecture, Structural Engineering, Plumbing, Mechanical, Electrical

SIZE: 159,749 SF

SCOPE: New construction

DETAILS:

  • Independent living - 157 beds

  • Assisted living - 33 beds

  • Memory care - 24 beds

  • Clubhouse

  • Wellness Center



1/3

ARBOR LANDING

Independent Living

Ocean Isle, NC

Triad Design Group was retained by RidgeCare, Inc. to provide Architectural, Structural, Plumbing, HVAC and Electrical Engineering services for Arbor Landing at Ocean Isle Beach, NC.  The facility is a two story 61,600 SF, 70 unit independent living apartment building for the elderly.  Included in the design are a central dining room, commercial kitchen, private dining area, living room, bar/lounge, library, exercise/therapy room and various activity rooms.  At the owner’s request, the building’s construction type is designed for possible future conversion to state licensed assisted living care. The ground floor may include an Alzheimer’s Care wing.

SERVICES: Architecture, Civil Engineering, Structural Engineering, Planning

SIZE: 61,600 SF

SCOPE: New construction

DETAILS:

  • Independent living - 70 beds

  • Stand-alone facility



BRIGHTWATER

1/6

CONTINUING CARE RETIREMENT COMMUNITY

Myrtle Beach, SC

TDG was retained by Senior Living Communities to provide Architectural, Structural, Mechanical, Electrical and Plumbing design services for the new campus at Brightwater in Myrtle Beach, SC.  The campus includes a 20,000 SF Clubhouse, three 43,500 SF apartment buildings, a 13,395 SF Assisted Living Building with a separate

6,700 SF dining facility, a 15,639 SF Nursing Care Building, a Wellness Center that includes an indoor therapy pool, a 1,000 SF maintenance building, a gatehouse and gazebo.  The Clubhouse is a two-story structure with dining rooms to seat 240 people, a kitchen, an activities room, a library and offices and other support spaces. The Apartment Buildings are three-story structures with 30 units each.  The Assisted Living Building is a single story structure containing 33 residential beds.  The Nursing Care Building is a single-story structure with 32 beds.  The campus also includes an outdoor pool and bathhouse for all residents.

SERVICES: Architecture, Civil Engineering, Structural Engineering, Planning

SIZE: 187,234 SF

SCOPE: New construction

DETAILS:

  • Independent living - 157 beds

  • Assisted living - 33 beds

  • Nursing care - 32 beds

  • Clubhouse

  • Wellness center


1/8

HOMESTEAD HILLS

CONTINUING CARE RETIREMENT COMMUNITY

Winston-Salem, NC

Full-service design and consulting services for the Homestead Hills apartments and clubhouse in Winston-Salem, North Carolina.  The three building complex on a seven acre site completes an existing continuing care community which includes single family independent living neighborhoods as well as assisted living facilities. Two three-story wood framed apartment buildings totaling 89,129 SF provide 62 residential units with site provisions for a future third apartment building.  The two-story 20,704 SF clubhouse includes administrative offices and the dining and social facilities for the residents.

SERVICES: Architecture, Civil Engineering, Structural Engineering, Planning

SIZE: 109,833 SF

SCOPE: New construction

DETAILS:

  • Independent living - 96 beds

  • Nursing care - 40 beds

  • Memory Care - 24 Beds

  • Clubhouse

  • Wellness center



LAKES POINTE WEST

1/7

SERVICES: Architecture, Civil Engineering, Structural Engineering

SIZE: 136,350 SF

SCOPE: New construction

DETAILS:

  • Independent living

  • Assisted living

  • Memory Care

  • Clubhouse

  • Wellness center

CONTINUING CARE RETIREMENT COMMUNITY

Vero Beach, FL

Architecture and Engineering design services for the six buildings in the first phase of the retirement community in Vero Beach, Florida.  The project included a clubhouse / administrative building of 16,400 sf, two three-story apartment buildings of 43,500 sf each, a dining facility of 5,800 sf, an assisted living care facility of 12,650 sf, an Alzheimer’s care facility of 14,500 sf and a
gatehouse and maintenance building.


1/5

MCCARTHY COURT

INDEPENDENT LIVING

New Bern, NC

TDG provided Architectural and Structural Engineering services for McCarthy Court 3 Senior Living Apartments.  The 30 unit, 40,907 SF apartment building is located in New Bern, NC, and is the third phase of an existing assisted living and independent living senior campus.  The facility is connected by covered walkway to the existing Phase 2 building, which houses the commercial kitchen and dining room.  McCarthy Court 3 includes a grand living room, screened porch, and patio.

SERVICES: Architecture, Civil Engineering, Structural Engineering

SIZE: 40,907 SF

SCOPE: New construction

DETAILS:

  • Independent living - 30 beds

  • Stand-alone facility



OSPREY VILLAGE

1/7

SERVICES: Architecture, Civil Engineering, Structural Engineering, Planning

SIZE: 38,200 SF

SCOPE: New construction

DETAILS:

  • Independent living - 60 beds

  • Assisted living - 48 beds

  • Nursing Care - 36 beds

  • Memory Care - 36 beds

  • Clubhouse

  • Wellness Center

CONTINUING CARE RETIREMENT COMMUNITY

Amelia Island, FL

TDG was retained by Aaron Properties to provide Architectural, Structural, Mechanical, Electrical and Plumbing design services for the Assisted Living Building and Clubhouse at Osprey Village.  The Assisted Living Building is a single story structure of 29,200 SF containing 48 residential beds.  The facility contains dining and living rooms, an activity area, offices, storage and support spaces.  The Clubhouse is a two-story structure of 9,000 SF with dining rooms to seat 150 people.  The dining area is supplemented with a kitchen, game rooms, a library, offices and support spaces to accommodate the independent living residents within the development.

1/7

OSPREY VILLAGE - AMENITY

CONTINUING CARE RETIREMENT COMMUNITY

Amelia Island, FL

TDG was contracted to design the new pool amenity building to compliment the original design.

SERVICES: Architecture, Civil Engineering, Structural Engineering

SIZE: 3,338 SF

SCOPE: New construction

DETAILS:

  • +/- 640 sf saltwater pool

  • Restroom facilities

  • Insulated CMU structural walls with pre-engineered wood trusses




PARKWOOD VILLAGE

SERVICES: Architecture, Civil Engineering, Structural Engineering, Planning

SIZE: 79,176 SF

SCOPE: New construction

DETAILS:

  • Assisted living - 50 beds

  • Memory Care - 20 beds

  • Stand-alone facility

1/7

INDEPENDENT LIVING COMMUNITY

Wilson, NC

Architectural, Structural and Civil Engineering services for Parkwood Village Independent Living Apartments.  The apartments are located on the existing Parkwood Village Campus in Wilson, NC.  The building is a three story structure of 79,176 sf containing 60 residential apartment units.  The facility contains dining rooms, multi-purpose room, library, exercise facilities, offices, storage and support spaces.


1/4

WATERSONG AT VIERA

CONTINUING CARE RETIREMENT COMMUNITY

Melbourne, FL

TDG was retained by Senior Living Communities to provide Architectural, Structural, Mechanical, Electrical and Plumbing design services for the new campus Watersong at Viera in Melbourne, FL.  The campus includes a 20,000 SF Clubhouse, three 43,500 SF Apartment Buildings, a 13,395 SF Assisted Living Building with its own Clubhouse, a 14,854 SF Alzheimer’s Care Building, a Wellness Center that includes an indoor therapy pool, a 1,000 SF maintenance building, and a gatehouse and gazebo.  The Clubhouse is a two-story structure with dining rooms to seat 240 people, a kitchen, an activities room, a library and offices and other support spaces. The Apartment Buildings are three-story structures with 30 units each.  The Assisted Living Building is a single story structure containing 33 residential beds.  The Alzheimer’s Care Building is a single-story structure with 32 beds.  The campus also includes an outdoor pool and bathhouse for all residents.

SERVICES: Architecture, Civil Engineering, Structural Engineering, Planning

SIZE: 179,749 SF

SCOPE: New construction

DETAILS:

  • Independent living - 157 beds

  • Assisted living - 33 beds

  • Memory Care - 24 beds

  • Clubhouse

  • Wellness center



WELLMORE HEALTHCARE CAMPUS

CONTINUING CARE RETIREMENT COMMUNITY

Tega Cay , SC

In 2011, Donald Thompson, with the Maxwell Group/Senior Living Communities retained Triad Design Group to design a new prototype health care campus. The new campus was to provide Assisted Living, Alzheimer’s Care and Nursing Care services. Included also were a Clubhouse/Wellness Center to provide centralized administrative offices, living, dining, activity spaces and wellness programs for campus residents. The Wellness Center is a key component of the services program and includes exercise rooms, rehab therapy rooms and a heated therapy pool. Nursing Care and Alzheimer’s Care building plans are based on a lower care-giver to resident ratio with only twelve bedrooms per Staff Care Station.  The name Well-more reinforces the program of wellness care.



The campus design includes six buildings, all connected by enclosed corridors to provide climate controlled access between buildings for all residents and staff. Each building has direct access from parking areas for staff and family members. Visitors gain controlled access through the Clubhouse. There is a 27,000 SF Clubhouse, two two-story 32,000 SF Assisted Living Care buildings, two 19,000 SF Nursing Care Buildings and one 18,600 SF Alzheimer’s Care building for a total campus enclosed building area of 147,600 SF.



Sites are to be located near larger urban areas in various cities across the southeast. Tega Cay, South Carolina near the city of Charlotte, North Carolina and surrounding suburban development is the first location.

SERVICES: Architecture, Civil Engineering, Structural Engineering, Planning

SIZE: 147,600 SF

SCOPE: New construction

DETAILS:

  • Assisted living - 128 beds

  • Nursing Care - 60 beds

  • Memory Care - 30 beds

  • Clubhouse

  • Wellness center

1/13

1/12

WELLMORE HEALTHCARE
CAMPUS

CONTINUING CARE RETIREMENT COMMUNITY

Lexington , SC

Architectural, Civil, and Structural design services for an additional Wellmore Healthcare Campus located in Lexington, SC just outside of Columbia, SC.

SERVICES: Architecture, Civil Engineering, Structural Engineering

SCOPE: New construction

DETAILS:

  • Assisted living - 114 beds

  • Nursing Care - 60 beds

  • Memory Care - 60 beds

  • Clubhouse

  • Wellness center

Architecture | Civil | Structural | Planning

Port St. Lucie, FL

Continuing Care Retirement Community


Features:

  • Independent living - 157 beds

  • Assisted living - 33 beds

  • Memory care - 24 beds

  • Clubhouse

  • Wellness Center



WELLMORE HEALTHCARE CAMPUS

CONTINUING CARE RETIREMENT COMMUNITY

Daniel Island, SC

Architectural, Civil, and Structural design services for an additional Wellmore Healthcare Campus located in Daniel Island, SC just outside of Charleston, SC.

SERVICES: Architecture, Civil Engineering, Structural Engineering

SCOPE: New construction

DETAILS:

  • Assisted living - 114 beds

  • Nursing Care - 60 beds

  • Memory Care - 60 beds

  • Clubhouse

  • Wellness center

1/23

1/8

WILDEWOOD DOWNS

CONTINUING CARE RETIREMENT COMMUNITY

Columbia , SC

Architecture and Engineering design services for the six building first phase of the retirement community.  The first phase contains a clubhouse / administrative building of 16,400 SF, two three story apartment buildings of 43,500 SF each, a dining facility of 5,800 SF, an assisted living care center of 12,650 SF, an Alzheimer’s care center of 14,500 SF and a gatehouse and maintenance building.

SERVICES: Architecture, Civil Engineering, Structural Engineering, Planning

SIZE: 136,350 SF

SCOPE: New construction

DETAILS:

  • Assisted living - 24 beds

  • Nursing Care - 24 beds

  • Clubhouse

  • Wellness center
